    Product attributes

    General Description
    Raw material
    PE
    Material type
    foam
    Additional feature
    anti-static
    Finishing: foam
    cross linked, from 1 layer
    Color
    pink
    Cell structure
    closed cell
    Hardness (Shore 00)
    45 Shore 00
    Density
    33 kg/m³
    Density range and norm
    28 to 28 kg/m³ (DIN EN ISO 845)
    Possibilities Material
    Self adhesive possibilities
    1 side, 2 sides, without adhesive
    Most sold thicknesses
    5, 10, 15, 20, 25, 30, 40, 50 mm
    Minimum thickness
    2 mm
    Maximum thickness
    100 mm
    Non standard thicknesses
    easily created by splitting blocks
    Dimension sheet
    1000 x 2000 mm
    UV resistance
    good
    Ozone resistance
    good
    Sealing for which joint types
    level/parallel
    Technical Properties Material
    Temperature range
    -40 °C to +90 °C, intermittent +100 °C
    FMVSS302
    compliant
    Linear shrinkage 22h, 70 °C
    < 5%
    Thermal conductivity
    0,037 W/mK
    Water absorption
    < 1% (DIN 53428)
    Compression deflection 10%
    35 kPa
    Compression deflection 25%
    55 kPa (40 - 80 kPa, DIN EN ISO 844)
    Compression deflection 50%
    130 kPa (80 - 160 kPa, DIN EN ISO 844)
    Compression set: 25%, 22 h, 23 °C: after 30 min
    < 15% (DIN EN ISO 1856)
    Compression set: 25%, 22h, 23 °C: after 24h
    < 7% (DIN EN ISO 1856)
    Tensile strength kPa
    220 kPa (> 175 kPa, DIN EN ISO 1798)
    Elongation
    140% (> 120%, DIN EN ISO 1798)
    Maximum % of compression
    50%
    Volume resistivity
    >10E12
    Applications, Standards
    REACH
    compliant
    RoHS
    compliant
    Recyclable
    compliant
    CFC and HCFC free
    compliant
    Shelf life
    2 years
    HS code
    3901101090
    General Description
    Raw material
    PE
    Material type
    foam
    Additional feature
    anti-static
    Finishing: foam
    cross linked, from 1 layer
    Color
    pink
    Cell structure
    closed cell
    Hardness (Shore 00)
    45 Shore 00
    Density
    33 kg/m³
    Density range and norm
    28 to 28 kg/m³ (DIN EN ISO 845)
    Possibilities Material
    Self adhesive possibilities
    1 side, 2 sides, without adhesive
    Most sold thicknesses
    5, 10, 15, 20, 25, 30, 40, 50 mm
    Minimum thickness
    2 mm
    Maximum thickness
    100 mm
    Non standard thicknesses
    easily created by splitting blocks
    Dimension sheet
    1000 x 2000 mm
    UV resistance
    good
    Ozone resistance
    good
    Sealing for which joint types
    level/parallel
    Technical Properties Material
    Temperature range
    -40 °C to +90 °C, intermittent +100 °C
    FMVSS302
    compliant
    Linear shrinkage 22h, 70 °C
    < 5%
    Thermal conductivity
    0,037 W/mK
    Water absorption
    < 1% (DIN 53428)
    Compression deflection 10%
    35 kPa
    Compression deflection 25%
    55 kPa (40 - 80 kPa, DIN EN ISO 844)
    Compression deflection 50%
    130 kPa (80 - 160 kPa, DIN EN ISO 844)
    Compression set: 25%, 22 h, 23 °C: after 30 min
    < 15% (DIN EN ISO 1856)
    Compression set: 25%, 22h, 23 °C: after 24h
    < 7% (DIN EN ISO 1856)
    Tensile strength kPa
    220 kPa (> 175 kPa, DIN EN ISO 1798)
    Elongation
    140% (> 120%, DIN EN ISO 1798)
    Maximum % of compression
    50%
    Volume resistivity
    >10E12
    Applications, Standards
    REACH
    compliant
    RoHS
    compliant
    Recyclable
    compliant
    CFC and HCFC free
    compliant
    Shelf life
    2 years
    HS code
    3901101090
    Disclaimers

    The published technical data is based on research data and serves as a guide for the various applications. Due to the great diversity of products and application possibilities, the buyer must test himself whether the intended material meets the requirements. All information is subject to typing errors, mistakes and market developments and no rights can be derived from this.
